Nickel 201 (Ni 201), also known as Alloy 201 with UNS N02201 and W.Nr. 2.4068, is a high-purity nickel alloy known for excellent corrosion resistance, particularly in alkaline environments and organic acids. This alloy is ideal for chemical processing, aerospace, and food processing applications, offering strong resistance to high temperatures and stress corrosion cracking.
With good weldability and formability, Nickel 201 is widely used in the manufacturing of components such as heat exchangers, electrical components, and precision instruments. Its resistance to corrosion and excellent mechanical properties make it a reliable choice for harsh environments requiring high-performance materials.
| Nickel (Ni) | 99.0% minimum |
| Copper (Cu) | 0.25% maximum |
| Iron (Fe) | 0.40% maximum |
| Manganese (Mn) | 0.35% maximum |
| Carbon (C) | 0.02% maximum |
| Silicon (Si) | 0.35% maximum |
| Sulfur (S) | 0.01maximum |
| Density | lb/in3 | 0.321 |
| g/cm3 | 8.89 | |
| Melting Range | °F | 2610-2630 |
| °C | 1435-1445 | |
| Specific Heat | Btu/lb•°F | 0.109 |
| J/kg•°C | 456 | |
| Curie Temperature | °F | 680 |
| °C | 360 | |
| Modulus of Elasticity (Tension) | 103ksi | 30 |
| GPa | 207 |
|
Temperature |
Yield strength |
Yield strength |
Tensile strength |
Elongation |
||||
|
Rp 0.2 |
Rp 1,0 |
Rm |
A |
|||||
|
°C |
°F |
MPa |
ksi |
MPa |
ksi |
MPa |
ksi |
% |
|
20 |
68 |
80 |
11.6 |
105 |
15.2 |
340 |
49.3 |
40 |
| Rod and bar | Seamless Pipe and Tube | Welded Pipe and Tube | Plate, Sheet & Strip | Fittings |
| ASTM B 160/ ASME SB 160 | ASTM B 161/ ASME SB161, ASTM B 163/ ASME SB163 | ASTM B 725/ ASME SB 725, ASTM B 730/ ASME SB 730 | ASTM B 162/ ASME SB 162 | ASTM B 366/ ASME SB 366 |
Standard product forms of Nickel 201/Ni 201/Alloy 201/UNS N02201/W.Nr. 2.4068 are pipe, tube, sheet, strip, plate, round bar, flat bar, forging stock, hexagon and wire. The products are available in a wide variety of sizes. Please contact us at [email protected] for full information.
